Typically the base which is bolted into a big concrete pad provides the necessary support for a tower crane. The base is attached to a mast or a tower and stabilizes the crane that is affixed to the inside of the building's structure. Usually, this attachment point is to an elevator shaft or to a concrete lift.
The mast of the crane is usually a triangulated lattice structure that measures 10 feet square or 0.9m2. Attached to the very top of the mast is the slewing unit. The slewing unit is made of a motor and a gear that enable the crane to rotate.
Tower cranes may have a max unsupported height of 80m or 265 feet, while the tower crane's maximum lifting capacity is 16,642 kg or 39,690 pounds with counter weights of 20 tons. Furthermore, two limit switches are utilized to be able to ensure the operator does not overload the crane. There is even another safety feature called a load moment switch to ensure that the operator does not surpass the ton meter load rating. Last of all, the maximum reach of a tower crane is 230 feet or 70 meters.
Because of their extreme heights, there is a science involved to erecting a crane. The stationary structure will at first have to be transported to the construction location by using a huge tractor-trailer rig setup. Next, a mobile crane is utilized so as to assemble the machine part of the crane and the jib. These sections are then connected to the mast. The mobile crane then adds counterweights. Forklifts and crawler cranes could be some of the other industrial machinery which is utilized to erect a crane.
When the building is erected, mast extensions are added to the crane. This is how the crane's height is able to match the building's height. The crane crew uses what is referred to as a climbing frame or a top climber that fits between the slewing unit and the top of the mast. A weight is hung on the jib by the work crew so as to balance the counterweight. When complete, the slewing unit could detach from the top of the mast. In the top climber, hydraulic rams are used to adjust the slewing unit up an additional 20 feet or 6.1m. After that, the operator of the crane utilizes the crane to insert and bolt into position another mast part piece.
