Genie telescopic S-booms have working heights of 14.20 meters to 40.15 meters and a horizontal reach of between 9.65 meters and 24.38 meters. Compared with various other aerial work platforms, telescoping booms have a much greater range of horizontal reach. Genie telescopic booms are engineered with consideration to being able to access confined places during construction and industrial applications. They are also known for their ability to maneuver through a job site rapidly and with great drive speed and traction. The platform turns 160�° hydraulically and is able to stay level through the whole range. Front-entry platforms come with 227 kilogram to 272 kilogram capacity for operators and tools and are available from 1.83 meters to 2.44 meters. 360�° continuous rotating turntables offer quick, easy positioning for operators.
The Z-135/70 unit has a telescoping jib, known as the Jib-Extend, which goes from 3.66 meters to 6.1 meters. This unit can also reach 110�° vertically to give the user the ability to reach tasks which were previously inaccessible by standard jibs. A secondary reverse-articulating boom on the Z-80/60 unit gives the user 8.83 meters of up and over reach. This feature allows over and up reaching jobs to be done with zero front arm swing.
Genie also provides the Fast Mast system that allows for valuable time to be saved when both primary and secondary booms need to be lifted or for lowering the platform without having to lower the secondary boom. The Fast Mast system allows both booms to be fully elevated at the same time. Both of these features of the Genie Fast Mast system lessens the time needed for users to descend and ascend, increasing both effectiveness and production.
